SDA508

PN
:SDAXX7XX0X00
没有此类产品
在线咨询
产品描述
Specification Type
Pitch 5.08
NO.of Positions 2P~24P
Termination methods -
Type DIP
Material Properties
Insulator  PA66
Contact Brass
Contact plating TIN
Flammability UL94 V0
ROHS Compliant ROHS
Technical Specs
Current rating  A
Voltage rating 250V
Withstanding voltage 1.5KV
Contact resistance 20m Max
Insulation resistance 5000M Min
Wire range 22-16 AWG
Insertion/Withdrawal force -
Mechanical life cycle 100
Operating temperature -40℃~105℃
Safety Approval
Standard of safety UL1059
Number E355923
